Item Details:

• Lens
• FOV
• Horizontal field of view: 100° to 33° (Wide-Tele),Vertical field of view: 53° to 18° (Wide-Tele),Diagonal field of view: 119° to 37.5° (Wide-Tele)
• Zoom Speed
• Approx. 2 s (optical lens, wide-tele)
• Working Distance
• 10 mm to 1500 mm (wide-tele)
• Aperture Range
• F1.6 to F2.7
• Focal Length
• 2.8 mm to 12 mm, 4× optical zoom
• Image
• Image Enhancement
• 3D DNR, EIS, Regional Exposure, Regional Focus
• Sub-Stream
• 50Hz: 25fps (704 × 576, 640 × 480, 352 × 288),60Hz: 30fps (704 × 480, 640 × 480, 352 × 240)
• Max. Resolution
• 2560 × 1440
• Main Stream
• 50Hz: 25fps (2560 × 1440, 2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720),60Hz: 24fps (2560 × 1440), 30fps(2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720)
• Third Stream
• 50Hz: 25fps (1280 × 720, 704 × 576, 640 × 480, 352 × 288),60Hz: 30fps (1280 × 720, 704 × 480, 640 × 480, 352 × 240)
• Network
• Network Storage
• Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB; NAS (NFS, SMB/ CIFS), ANR
• Protocols
• IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, DHCP, PPPoE, Bonjour
• API
• Open-ended, support ONVIF, ISAPI, and CGI, support HIKVISION SDK and Third-Party Management Platform
• Simultaneous Live View
• Up to 20 channels
• User/Host
• Up to 32 users,3 levels: Administrator, Operator and User
• Client
• iVMS-4200, iVMS-4500, iVMS-5200, Hik-Connect
• Web Browser
• IE 8 to 11, Chrome 31.0 to 44, Firefox 30.0 to 51, Safari 8.0+
• Security Measures
• User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x port-based network access control; IP address filtering
• Alarm Linkage
• Alarm actions, such as Memory Card Video Record, Trigger Recording, Notify Surveillance Center, Upload to FTP/Memory Card/NAS, Send Email, etc.
• Interface
• Power Output
• 12VDC, max. 60 mA
• Audio Input
• 1-ch audio input
• Audio Output
• 1-ch audio output
• Network Interface
• 1 RJ45 10 M/100 M Ethernet Interface, Hi-PoE
• Compression Standard
• H.264+
• Yes
• H.265+
• Yes
• H.264 Type
• Baseline Profile/Main Profile/High Profile
• Video Compression
• Main Stream: H.265+/H.265/H.264+/H.264,Sub-stream: H.265/H.264/MJPEG,Third Stream: H.265/H.264/MJPEG
• Video Bitrate
• 32 Kbps to 16384 Kbps
• Audio Compression
• G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM
• Audio Bitrate
• 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 Kbps to 160 Kbps(MP2L2)
• SVC
• Yes
• Camera Module
• Image Sensor
• 1/3" progressive scan CMOS
• Min. Illumination
• Color: 0.005 Lux @(F1.6, AGC ON),B/W: 0.001 Lux @(F1.6, AGC ON),0 Lux with IR
• White Balance
• Auto/Manual/ATW (Auto-tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp
• Gain
• Auto/Manual
• Shutter Time
• 50Hz: 1/1 s to 1/30,000 s,60Hz: 1/1 s to 1/30,000 s
• Day & Night
• IR cut filter
• Digital Zoom
• 16×
• Privacy Mask
• 24 programmable privacy masks
• Focus Mode
• Auto/Semi-automatic/Manual
• WDR
• 120 dB WDR
• Supplement Light
• IR Distance
• 20 m
• Smart IR
• Yes
• PTZ
• Movement Range (Pan)
• 0° to 355°
• Pan Speed
• Configurable, from 0.1°/s to 100°/s, ,Preset speed: 100°/s
• Movement Range (Tilt)
• From 0° to 90°
• Tilt Speed
• Configurable, from 0.1°/s to 100°/s,Preset Speed: 100°/s
• Proportional Zoom
• Yes
• Presets
• 300
• Power-Off Memory
• Yes
• Smart Features
• Basic Event Detection
• Motion Detection, Video Tampering Detection, Exception
• Smart Detection
• Face Detection, Intrusion Detection, Line Crossing Detection, Region Entrance Detection, Region Exiting Detection, Object Removal Detection, Unattended Baggage Detection, Audio Exception Detection
• Smart Record
• ANR (Automatic Network Replenishment), Dual-VCA
• ROI
• Main stream, sub-stream, and third stream respectively support four fixed areas.
• General
• Material
• Aluminum alloy, PC, PC+ABS
• Dimensions
• Φ 130.7 mm × 101.7 mm (Φ 5.15" × 4.00")
• Weight
• Approx. 0.53 kg (1.17 lb)
• Protection Level
• IP66 Standard, IK 10, Surge Protection, ±2kV Line to Gnd, ±1kV Line to Line, IEC61000-4-5
• Power
• 12 VDC, 1.5 A (Max. 9.9 W, including max. 4.2 W for IR)
• PoE (802.3af), 36 to 57 VDC, 0.35 A (Max. 11.2 W, including max. 4.2 W for IR)
• Working Temperature
• -20°C to 60°C (-4°F to 140°F)
• Working Humidity
• ≤ 90%
